General Specifications
- Operating voltage : 9 – 16V
- RMS power @ 4 ohms – 4x60W
- RMS power @ 2 ohms – 2x70W
- RMS bridged power @ 4 ohms – 1x140W
- Total peak power 560W
- Frequency response 20Hz – 20kHz @ -1dB
- THD + N at rated power
- (20Hz – 20kHz) <1%
- Line-in signal-to-noise ratio
- (reference to 1 watt) >75dB
- Maximum high input signal level 12V
- High input maximum sensitivity 0.5V
- Maximum line input signal level 5V
- Line input maximum sensitivity 0.2V
- Quiescent current draw <1.5A
- Fuse size 2 x 15A
- Dimensions (H x W x L) 50 x 145 x 193.6mm
