Ειδικά χαρακτηριστικά
Χρησιμοποιώντας το ενσωματωμένοphono stage, το TD 201 μπορεί να συνδεθεί με οποιοδήποτε ενισχυτή ακόμη και αν δεν διαθέτει συγκεκριμένη είσοδο για συσκευές phono.
Turntable section
Drive System Belt Drive
Motor DC Motor
Speed 33 1/3 RPM, 45 RPM
Rotation Speed Variation +/–2%
Wow and Flutter 0.2%
Signal-to-Noise Ratio 67dB or higher (A-weighted, 20kHz LPF) 60dB or higher (unweighted, 20kHz LPF)
Platter Aluminum Die-cast Diameter of Platter 12", 300mm
Tonearm section Alumi tube
Type Static Balance, Straight
Effective Arm Length 8.8", 223.6mm
Stylus Pressure Range 0 to 4g
Supported Cartridge Weight 3.5 to 6.0g
Overhang 18.6mm
Anti-skating Adjustment Supported
Cartridge section
Type MM type (Audio-Technica AT3600)
Stylus Construction Bonded Diamond
Frequency Response 20Hz to 20kHz
Channel Separation >18dB Channel Balance 2.5dB
Vertical Tracking Angle 20 degrees
Supported Load Impedance 47k ohms
Output Voltage 2.5mV (1kHz, 3.54cm/sec.)
Stylus Pressure 3.5g +/–0.5g
Cartridge Weight 5g +/–0.5g
Head-shell Weight 10g (including Screws, Nuts and Wires)
Analog Output
Connector RCA Pin jack (Gold-plated)
Power AC 100 to 240V, 50/60Hz Power Consumption 1.5W (less than 0.5W at Standby)
Overall Dimensions (W x H x D) 420 x 355x 121mm
Weight Approx. 3.9 kg
