TAV-507F
YOUR MUSICAL JOURNEY!
New Generation Audio-Video series
Η νέα γενιά σειράς Audio-Video δεν αποτελεί εξέλιξη των προκατόχων της – είναι μια εντελώς νέα προσέγγιση στο σχεδιασμό και τον ήχο αυτής της σειράς. Η Audio-Video κατέχει ηγετική θέση στην ομάδα τιμών της εδώ και χρόνια, όσον αφορά την εξαιρετική σχεδίαση και τον ήχο που προσφέρεται σε προσιτές τιμές. Το στυλ, τα υλικά και η ποιότητα του ήχου της επόμενης γενιάς Audio-Video ενισχύουν περαιτέρω τη θέση της ως ηγέτης σε αυτό το τμήμα και πολύ περισσότερο. Το TAV-507F, ένα μοντέλο δαπέδου, ανοίγει τη σειρά και παρέχει τον εξαιρετικό ήχο για την τιμή τόσο στο στερεοφωνικό όσο και στο πολυκάναλο ηχοσύστημα, που αποτελεί χαρακτηριστικό της σειράς Audio-Video. Όπως πάντα, επικεντρωθήκαμε κυρίως σε εντατικά τεστ ακρόασης και προσαρμογές ήχου παρά στη δημιουργία τέλειων προδιαγραφών σε χαρτί, επειδή η μουσική και γενικά ο ήχος αφορά συναισθήματα, συναισθήματα και πάθος. Το τελικό αποτέλεσμα είχε ως αποτέλεσμα ηχεία που προσφέρουν βαθιά, τέλεια ελεγχόμενα και καθορισμένα μπάσα, ομαλά και πλούσια μεσαία και ελκυστικά, λεπτομερή και κρυστάλλινα ψηλά, καθώς και ένα πολύ ανοιχτό και ευάερο ηχοσκηνικό. Το TAV-507F ξεχωρίζει με τον λεπτομερή και πλούσιο ήχο που παράγεται από το μεταξωτό θόλο τουίτερ μας, την ανοιχτή και φυσική απόδοση μεσαίας κατηγορίας χάρη στο νέο πρόγραμμα οδήγησης μεσαίας κατηγορίας 5,25 ιντσών σε συνδυασμό με βαθιά και ζωντανά μπάσα που παράγονται από διπλά γούφερ 5,25 ιντσών. Το TAV-507F συνεχίζει περήφανα την κληρονομιά των προκατόχων του και αποδεικνύει ότι η σειρά Audio-Video μας είναι μια από τις καλύτερες ευκαιρίες στα ηχεία όλων των εποχών!
KEY FEATURES and changes compared to the previous generation
2nd generation TLIE-I enclosure (Taga Low Interference Enclosures) –more rigid structure to limit unwanted resonances: thicker 18 mm MDF front baffle (was 15 mm) and additional internal bracing.
Increased internal volume (the enclosure depth has grown from 23.5 cm to 25.9 cm) to provide better bass performance.
The steep enclosure top is leaned at around 4 degrees from the front to the rear to further limit unwanted resonances and turbulences.
Totally new feet with spikes – totally new Nylon feet and aluminum spikes.
The feet are exceptionally rigid and thick providing almost perfect isolation of speakers from the floor and increasing the transparency of sound as well as producing better definition and control for the bass.
Elegant and discreet feet design are based on the feet knows from the premium Platinum v.3 series.
They add extra chic to the TAV loudspeakers.
The design allows to interchangeably use the feet with spikes or only the spikes.
New high-quality enclosure damping material to better break up the standing waves, lower resonances and limit distortions what improves the smoothness and characteristics of sound in all ranges.
TAGA Harmony new logo badge placed on cabinet front panels, which is elegant and shows our strive and passion for perfect harmony of sound performance.
Upgraded 1” (25 mm) silk dome high-frequency driver with oversized Φ70 magnet, ferrofluid cooling and heavy duty copper voice coil can handle high power and its performance is very accurate, clear, smooth, detailed and airy sound.
2nd generation TWG-I tweeter faceplate (Taga WaveGuide) – specialized horn-like design of the tweeter’s faceplate utilizing concave diffusers assists with equal and flat dispersion of sound in and off the axis of the driver. In the newest edition the shape and depth have been redesigned to allow better flow of sound stream and even wider dispersion which helps to build a more three-dimensional and natural soundstage. Minimizing the number of components means better structural rigidity, lower distortions and resonances.
New 5.25” (133 mm) midrange driver – a bigger, more rigid and ultra-light polypropylene cone with elastic rubber suspension provide fast movement and smooth, rich and very natural midrange frequency response. Heavy duty voice coil and Φ70 magnet can stand high temperatures and power inputs. The flat dust cap supports air flow and smoothens the frequency response.
Upgraded dual 5.25” (133 mm) woofer drivers – ultra-light polypropylene cone with elastic rubber suspension, Φ80 magnet structure, heavy duty voice coil and coil former copped with more rigid driver chassis are built to withstand higher power handling and longer operation time without increasing driver temperature and in result to generate deeper, more musical and precise bass response. The flat dust cap supports air flow and smoothens the frequency response.
TAV-S
YOUR MUSICAL AND MOVIE JOURNEY!
New Generation Audio-Video series
The new generation Audio-Video series is not an evolution of its predecessors – it is a completely new approach to the design and sound of this line. Audio-Video has been a leader in its price group for years, in terms of fine design and sound offered in affordable prices. The style, materials and sound quality of the next Audio-Video generation further strengthen its position as a leader in this segment and far beyond.
When designing the TAV-S our objective was to create an eye-catching speaker with a great sound, which would be offered in a budget price which is a hallmark of the Audio-Video series.
As always we mostly focused on intensive listening tests and sound adjustments rather than on creating perfect specifications on paper because music and generally sound is about emotions, feelings and passion.
The final outcome resulted in a speaker which offers well controlled and defined bass, smooth and rich midrange and appealing, detailed and crystal clear highs as well as a very open and airy soundstage, which is so crucial for the stereo sound as well as for multichannel music and movies.
TAV-S with its detailed and rich high frequencies coupled with open and natural midrange backed by good bass is ideal for performing stereo music as well as movie soundtracks and multichannel music with lifelike dynamics and clarity.
TAV-S proudly continues the heritage of its predecessors and proves that our Audio-Video series is one of the best bargains in speakers ever!
KEY FEATURES and changes compared to the previous generation
2nd generation TLIE-I enclosure (Taga Low Interference Enclosures) –more rigid structure to limit unwanted resonances: thicker 18 mm MDF front baffle (was 15 mm).
New high-quality enclosure damping material to better break up the standing waves, lower resonances and limit distortions what improves the smoothness and characteristics of sound in all ranges.
TAGA Harmony new logo badge placed on the cabinet front panel, which is elegant and shows our strive and passion for perfect harmony of sound performance.
Upgraded 1” (25 mm) silk dome high-frequency driver with oversized Φ70 magnet, ferrofluid cooling and heavy duty copper voice coil can handle high power and its performance is very accurate, clear, smooth, detailed and airy sound.
2nd generation TWG-I tweeter faceplate (Taga WaveGuide) – specialized horn-like design of the tweeter’s faceplate utilizing concave diffusers assists with equal and flat dispersion of sound in and off the axis of the driver. In the newest edition the shape and depth have been redesigned to allow better flow of sound stream and even wider dispersion which helps to build a more three-dimensional and natural soundstage. Minimizing the number of components means better structural rigidity, lower distortions and resonances.
Upgraded 4” (102 mm) bass-midrange driver – ultra-light polypropylene cone with elastic rubber suspension provide fast movement and smooth, rich and very natural midrange frequency response as well as generate good bass. Heavy duty voice coil and Φ70 magnet can stand high temperatures and power inputs. The flat dust cap supports air flow and smoothens the frequency response.
Wall mount – factory wall mount offers ability for easy and fast installation on walls or other structures.
TAV-C
YOUR MUSICAL AND MOVIE JOURNEY!
New Generation Audio-Video series
The new generation Audio-Video series is not an evolution of its predecessors – it is a completely new approach to the design and sound of this line. Audio-Video has been a leader in its price group for years, in terms of fine design and sound offered in affordable prices. The style, materials and sound quality of the next Audio-Video generation further strengthen its position as a leader in this segment and far beyond.
When designing the TAV-C our objective was to create an eye-catching center speaker with a great sound, which would be offered in a budget price which is a hallmark of the Audio-Video series.
As always we mostly focused on intensive listening tests and sound adjustments rather than on creating perfect specifications on paper because music and generally sound is about emotions, feelings and passion.
The final outcome resulted in a center speaker which offers smooth and rich midrange and appealing, detailed and crystal clear highs as well as a very open and airy soundstage, which is so important in multichannel music and movies.
TAV-C with its detailed and rich high frequencies coupled with open and natural midrange is ideal for performing movie soundtracks and multichannel music with lifelike dynamics and clarity.
TAV-C proudly continues the heritage of its predecessors and proves that our Audio-Video series is one of the best bargains in speakers ever!
KEY FEATURES and changes compared to the previous generation
2nd generation TLIE-I enclosure (Taga Low Interference Enclosures) –more rigid structure to limit unwanted resonances: thicker 18 mm MDF front baffle (was 15 mm).
New high-quality enclosure damping material to better break up the standing waves, lower resonances and limit distortions what improves the smoothness and characteristics of sound in all ranges.
TAGA Harmony new logo badge placed on the cabinet front panel, which is elegant and shows our strive and passion for perfect harmony of sound performance.
Upgraded 1” (25 mm) silk dome high-frequency driver with oversized Φ70 magnet, ferrofluid cooling and heavy duty copper voice coil can handle high power and its performance is very accurate, clear, smooth, detailed and airy sound.
2nd generation TWG-I tweeter faceplate (Taga WaveGuide) – specialized horn-like design of the tweeter’s faceplate utilizing concave diffusers assists with equal and flat dispersion of sound in and off the axis of the driver. In the newest edition the shape and depth have been redesigned to allow better flow of sound stream and even wider dispersion which helps to build a more three-dimensional and natural soundstage. Minimizing the number of components means better structural rigidity, lower distortions and resonances.
Upgraded 4” (102 mm) bass-midrange driver – ultra-light polypropylene cone with elastic rubber suspension provide fast movement and smooth, rich and very natural midrange frequency response. Heavy duty voice coil and Φ70 magnet can stand high temperatures and power inputs. The flat dust cap supports air flow and smoothens the frequency response.
Wall mounts – factory wall mounts offer ability for easy and fast installation on walls or other structures.
| Design |
Floorstanding, 3-way, 4 drivers
TLIE-I enclosure
Crossover points: 550Hz, 3kHz |
| Power handling |
20 – 120W (recommended amplifier power)
90W RMS |
| Frequency response |
42Hz – 25kHz |
| Bassreflex |
Front single |
| Impedance |
6ohm |
| Sensitivity |
89dB |
| High-frequency driver |
25 mm (1”), TWG-I |
| Midrange driver |
133 mm (5.25″) |
| Bass driver |
2 x 133 mm (5.25″) |
| Features / accessories |
Feet
Aluminum spikes |
| Dimensions (H x W x D) |
92 x 17 x 25.9cm (excl. feet / spikes)
96.5 cm ( height incl. feet / spikes) |
| Weight |
10.5 kg / pc. (excl. feet) |
| Design |
Center, 2-way, 3 drivers
TLIE-I enclosure
Crossover points: 4.5kHz |
| Power handling |
20 – 100W (recommended amplifier power)
50W RMS |
| Frequency response |
55Hz – 25kHz |
| Impedance |
6ohm |
| Sensitivity |
88dB |
| High-frequency driver |
25 mm (1”), TWG-I |
| Bass-Midrange driver |
2 x 102 mm (4″) |
| Features / accessories |
Wall mounts |
| Dimensions (H x W x D) |
16.5 x 43 x 14.5 cm |
| Weight |
3.8 kg / pc. |
| Design |
Surround, 2-way, 2 drivers
TLIE-I enclosure
Crossover points: 4.5kHz |
| Power handling |
20 – 100W (recommended amplifier power)
50W RMS |
| Frequency response |
55Hz – 25kHz |
| Impedance |
6ohm |
| Sensitivity |
86dB |
| High-frequency driver |
25 mm (1”), TWG-I |
| Bass-Midrange driver |
102 mm (4″) |
| Features / accessories |
Wall mount |
| Dimensions (H x W x D) |
26.5 x 16.5 x 14.5 cm |
| Weight |
2.5 kg / pc. |
