Leave a review
|
SKU: 79354
Audiolab M-DAC+ - Black Audiolab M-DAC+ - Black Audiolab M-DAC+ - Black
free shipping
Audiolab M-DAC+ - Black
Audiolab M-DAC+ - Black
Audiolab M-DAC+ - Black

Audiolab M-DAC+ - Black

brand-logo

Το νέο M-DAC+ είναι ένα υψηλής απόδοσης, πολλαπλών χρήσεων ήχου DAC (Digital-to-Analogue Converter) για οικιακή χρήση, σχεδιασμένο για να κάθεται σε ένα γραφείο ή τραπέζι ή να ενσωματώνεται σε ένα σύστημα hi-fi. Ενσωματώνει έναν ψηφιακό προενισχυτή υψηλής ακουστικής ποιότητας και βαθμίδα εξόδου Κατηγορίας Α για σύνδεση με τελικό ενισχυτή και ηχεία (η έξοδος μπορεί να διορθωθεί για όσους επιθυμούν να χρησιμοποιήσουν έναν υπάρχοντα προενισχυτή ή ενσωματωμένο ενισχυτή), επιπλέον ποιοτική έξοδος για χρήση ακουστικών.



Available in 10 - 30 days
€1.339,00 Final Price
Add to cart
Do you have any questions or want to place a phone order? Call us at 2109401167
Buy Now Pay Later with the use of a debit card

We support installment purchases using a debit card. For details call us Phone

Free shipping all over Greece!

badge

After Sales Support

Supplier guarantee up toYears

star

Next to you since 1976

Over 46 years of experience!

group

Join us

Earn special offers

Alternative Suggestions
iFi Audio ZEN One Signature (5060738785612)
SKU: 57308

iFi Audio ZEN One Signature (5060738785612)

In Stock
€359,00
Cambridge Audio DacMagic 200M DAC - Lunar Grey
SKU: 58906

Cambridge Audio DacMagic 200M DAC - Lunar Grey

In Stock
€599,00
€399,00
Eversolo DAC-Z8 - Black 6975200360022
SKU: 84909

Eversolo DAC-Z8 - Black 6975200360022

In Stock
€739,00
Pro-Ject DAC Box E Black
SKU: 009338

Pro-Ject DAC Box E Black

In Stock
€119,00
Pro-Ject DAC Box E White
SKU: 009339

Pro-Ject DAC Box E White

In Stock
€119,00
iFi Audio NEO iDSD 2 (5060798787562)
SKU: 84956

iFi Audio NEO iDSD 2 (5060798787562)

In Stock
€899,00
Dynavox Mini-DAC ΙΙ DK-201C 207305
SKU: 0014271

Dynavox Mini-DAC ΙΙ DK-201C 207305

In Stock
€30,00
Dynavox Mini-DAC DK-201 (206957)
SKU: 007480

Dynavox Mini-DAC DK-201 (206957)

In Stock
€40,00
Musical Fidelity V90 DAC Black
SKU: 40108

Musical Fidelity V90 DAC Black

In Stock
€308,00
SoundMagic A30i ενισχυτής ακουστικών με lightning
SKU: 53003

SoundMagic A30i ενισχυτής ακουστικών με lightning

In Stock
€79,99
SoundMagic A30 DAC ενισχυτής ακουστικών με USB C
SKU: 50048

SoundMagic A30 DAC ενισχυτής ακουστικών με USB C

In Stock
€79,99
Fiio Q3 (6953175750086)
SKU: 48566

Fiio Q3 (6953175750086)

In Stock
€169,99
iFi Audio Zen DAC 3 (5060738788682)
SKU: 94754

iFi Audio Zen DAC 3 (5060738788682)

In Stock
€235,00
€234,00
iFi Audio Go Link ΜΑΧ (5060738789269 )
SKU: 97012

iFi Audio Go Link ΜΑΧ (5060738789269 )

In Stock
€85,00
Top seller
iFi Audio ZEN Air Dac (5060738786749)
SKU: 58074

iFi Audio ZEN Air Dac (5060738786749)

In Stock
€105,00
€104,00
iFi Audio UNO (5060738787234)
SKU: 69057

iFi Audio UNO (5060738787234)

In Stock
€80,00
€79,00

Redefining a Classic

The new M-DAC+ is based firmly on the classic M-DAC, with carefully targeted improvements in key areas – a logical move, given the original model’s sustained popularity over the last four years. The M-DAC built a peerless reputation with press and public alike since its launch in the autumn of 2011, scooping multiple Product of the Year Awards from the likes of What Hi-Fi?, Hi-Fi Choice and EISA to make it arguably the most critically acclaimed DAC component ever made. “The audiolab M-DAC+ gets an awful lot right – so much, in fact, it comfortably justifies its ‘+’ designation”. ~ What Hi-Fi? Sound and Vision, June 2016.

The Finest DAC Circuitry

Like the M-DAC, the M-DAC+ incorporates the ES9018 Sabre Reference 32-bit DAC chipset, still widely regarded as the finest available. This is surrounded by exceptionally well-specified circuitry that puts other similarly priced DACs to shame, including a proprietary, discrete master clock to minimise jitter, coupled with extensive time domain isolation. A JFET Class A output stage ensures that the audio signal, following conversion from the digital domain to analogue, is of the highest quality.

High Performance with DSD

Under the hood lie a number of performance-related enhancements. The M-DAC+ now processes audio data up to 32-bit/384kHz via USB; this is a far higher specification than that required by current hi-res music formats, ensuring this new, premium-quality addition to the M-DAC family is fully equipped for future advances in ultra-high-definition digital sound.

Pictured with 8300A Integrated amplifier.

The USB input now also accepts DSD files (the digital audio system originally developed for Super Audio CD), offering compatibility with DSD64, DSD128 and DSD256. This is a significant addition, as DSD has an important role to play in the developing high-resolution digital download scene.

Adjustable sound for all sources and tastes

As digital audio technology has progressed, the importance of the characteristics of reconstruction digital filters has become more appreciated. Like the classic M-DAC, the M-DAC+ features user-selectable filters for optimal listening and measurement modes, in addition to more conventional types for easy comparison. These filter settings allow the user to tune performance to suit his or her preference, depending on system configuration, digital file quality and musical taste. The M-DAC+ inherits seven filter settings from the M-DAC for PCM files and adds four more for DSD playback, allowing the user to optimise the noise floor to suit the performance of the source file and the bandwidth of associated equipment such as amps and speakers.

Enhanced Sonic Performance

Another important change relates to the power supply, which has been upgraded and is now incorporated within the M-DAC+’s chassis (hence its slightly taller and deeper case compared to the classic M-DAC). A precision-wound toroidal transformer uses multiple windings to feed separate analogue and digital rectification stages. From there, multiple power supply sections feed the necessary voltages to each area of the DAC, keeping any crossover interference to a minimum. The result is the highest performance power supply Audiolab engineers have yet specified for a DAC, and its contribution to the M-DAC+’s enhanced sonic performance is significant.

M-Dac+ Specifications

General description Digital-to-Analogue Converter
DAC ESS Sabre32 9018 chip
Sampling Rate 24-bit / 192kHz (Optical, Coaxial, AES)
32-bit / 384kHz (USB)
2.8MHz (DSD64), 5.6MHz (DSD128), 11.2MHz (DSD256)
Digital Input 2 x Coaxial, 2 x Toslink Optical, 1 x AES/EBU, 1 x USB for PC USB, 1x USB for iPod/iPhone/iPad
Digital Output 1x Coaxial, 1 x Toslink Optical
Output Voltage Balanced: 4.5V RMS
Unbalanced: 2.25V RMS
Output Impedance Balanced: 20Ω
Unbalanced: 10Ω
THD (1kHz 0dB 20Hz - 20kHz A wtd) <0.002%
Frequency Response 20Hz - 20kHz (± 0.2dB)
Signal to Noise Ratio RCA: > -115dB, XLR: > -120dB
Dynamic Range RCA: > 115dB, XLR: > 120dB
Crosstalk RCA: > 120dB, XLR: > 130dB
Dimensions (mm) 114mm x 247mm x 292mm
Net Weight 3.7kg
