SKU: 0014971
ATC SCM19 Cherry (Ζεύγος) ATC SCM19 Cherry (Ζεύγος)
ATC SCM19 Cherry (Ζεύγος)
ATC SCM19 Cherry (Ζεύγος)

ATC SCM19 Cherry (Ζεύγος)

brand-logo

New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.“SL” spec bass driver with 75mm integral soft dome.9kg optimised short-coil/long gap motor assembly.In-house, hand-wound precision flat wire coil.Flat impedance curve allowing easy load for amplifiers.6 year warranty.

Color

In Stock - Express παραλαβή και αποστολή από το κατάστημα
€3.600,00 Final Price
Add to cart
Do you have any questions or want to place a phone order? Call us at 2109401167
Buy Now Pay Later with the use of a debit card

We support installment purchases using a debit card. For details call us Phone

Type him postcode της περιοχής σας - ώστε να σας ενημερώσουμε για τους τρόπους αποστολής / παραλαβής.
badge

After Sales Support

Supplier guarantee up toYears

star

Next to you since 1976

Over 46 years of experience!

group

Join us

Earn special offers

Overview

  • New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
  • “SL” spec bass driver with 75mm integral soft dome.
  • 9kg optimised short-coil/long gap motor assembly.
  • In-house, hand-wound precision flat wire coil.
  • Flat impedance curve allowing easy load for amplifiers.
  • 6 year warranty.

Superlative clarity; excellent phase coherence; sublime bass.  Hi-Fi Choice Magazine, September 2014



Drivers: HF ATC 25mm Neodymium soft dome, Mid/LF ATC 150mm SL
Matched Response: ±0.5dB
Frequency Response (-6dB): 54Hz-22kHz
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Sensitivity: 85dB @ 1W @ 1metre
Max SPL: 108dB
Recommended Power Amplifier: 75 to 300 Watts
Nominal Impedance: 8 Ohm
Crossover Frequency: 2.5kHz
Connectors: Binding Posts/4mm Plugs, bi-wire
Cabinet Dimensions (HxWxD): 438x265x300mm (grill adds 28mm to depth)
Weight: 17.8kg
