Bright, Compact, Durable
The LS740HD incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods ofuse.3rd Generation Laser Phosphor Technology
Bright Images for Large Venues
Delivering 5,000 ANSI Lumens, the LS740HD provides vibrant and sharp projection in 1080p FHD in all lighting conditions for auditoriums, boardrooms, public venues, and other expansive spaces.5,000 ANSI Lumens
Unmatched Contrasts, Enhanced Visibility
The projector's high native contrast ratio, achieved through its Texas Instruments 0.65"DMD chip, enables deeper blacks and brighter whites. As a result, it delivers more visual depth, clearer images, and enhanced legibility.High Native Contrast Ratio
Ultra-large Screen with Lower Cost-per-inch
This easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.Up to 300”
Easy and Cost-effective Installation
The LS740HD is 35% lighter in weight and 35% smaller in size compared to its predecessor and even most competing projectors in the market, greatly reducing the cost of transportation and increasing the ease of installation.Lighter Weight, Compact Size
Save on Costs and Energy
With its advanced lamp-free light source, the LS740HD offers a highly energy-efficient and cost-saving display solution by consuming up to 51% less power than competing projectors.Less Power Consumption
Enhanced Installation Flexibility
Equipped with a 1.3x optical zoom, the projector allows users to choose the most ideal set-up location with in a range, getting the desired image size without needing to change the existing interior design. 1.3x Optical Zoom
Get Perfectly-shaped Images Effortlessly
Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.H/V Keystone Correction, 4 Corner Adjustment
Versatile Creative Applications
The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.360° Projection, 90° Portrait Mode
Present the Best with Vibrant Colors
Impress any audience with ViewSonic’s exclusive color technology, elevating your present ation with a true-to-life color experience.
Non-stop 24/7 Operation
The projector's advanced cooling design enables 24/7 operation without any degradation in image quality or performance. This makes it the go-to solution for applications that require continuous projection in retail stores, malls, museums, airports, and other public spaces.
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily via USB cable connection with your own laptop.
Learn more: https://youtu.be/irlhJLpDHas
*The latest projector software update can be found in the download section at the bottom of the page when available.
Directly Power Wireless HDMI Dongle
The built-in 5V/1.5A USB-A output conveniently delivers power to a wireless HDMI dongle, eliminating the need for separate power adapters when streaming multi media content.USB-A Power Supply
Enhanced Dust Resistance
Maintain crystal-clear image quality and product longevity with an advanced IP6X sealed engine design that prevents dust from entering and affecting internal components.IP6X
Dimensions & I/O Ports
Front IR- Lens
- Focus Ring
- HDMI x2
- RS232
- USB-A (5V/1.5A, Service)
- Audio Out
- DC In
- Zoom Ring
- Power Button
- Keypad
- Top IR
SPECIFICATIONS
- Specification
- Projection System: 0.65" 1080P
- Native Resolution: 1920x1080
- Brightness: 5000 (ANSI Lumens)
- Brightness (Center Lumens): 5500
- Contrast Ratio: 3000000:1
- Display Color: 1.07 Billion Colors
- Light Source Type: Laser Phosphor
- Light Source Life (hours) with Normal Mode: 20000
- Light Source Life (hours) with SuperEco Mode: 30000 (Eco)
- Lens: F=2.43-2.78, f=16.90-21.61mm
- Projection Offset: 132%+/-10%
- Throw Ratio: 1.13-1.47
- Optical Zoom: 1.3X
- Digital Zoom: 0.8x-2.0x
- Image Size: 30"-300"
- Throw Distance: 0.75-9.76m
- (100"@2.50m)
- Keystone: H:+/-30° , V:+/-30°
- Audible Noise (Normal): 30dB
- Audible Noise (Eco): 24dB
- Input Lag: 49.5ms
- Resolution Support: VGA(640 x 480) to WUXGA RB(1920 x 1200)
- *RB-Reduced Blanking
- HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
- Horizontal Frequency: 15K-102KHz
- Vertical Scan Rate: 24-120Hz
- Input
- HDMI: 2
- (HDMI 1.4/ HDCP 1.4)
- Output
- Audio-out (3.5mm): 1
- Speaker: 15W
- USB Type A (Power): 1 (5V/1.5A)
- Control
- RS232 (DB 9-pin male): 1
- USB Type A (Services): 1
- (share with USB A Output)
- Others
- Power Supply Voltage: Power adaptor:
- Input: 100~240V
- Output: 19.5VDC / 11.79A
- Power Consumption: Normal: 210W
- Standby: <0.5W
- Operating Temperature: 0~40℃
- Carton: Brown
- Net Weight: 3.00kg
- Gross Weight: 4.70kg
- Dimensions (WxDxH) with Adjustment Foot: 286x216x129mm
- Packing Dimensions: 400x280x155mm
- OSD Language: English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese,Japanese, Turkish, Portuguese, Finnish, Indonesian, Arabic, Vietnamese, Hungarian, Norsk, total 23 languages
- User Guide Language: English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese, total 20 languages
- Standard Accessory
- Power Cord: 1
- Remote Control: 1
- QSG: Yes
- Warranty Card: Yes (CN Only)
- Optional Accessory
- Wall/Ceiling Mount: PJ-WMK-007
- Carry Bag: PJ-CASE-008
