• Μεταλλική και στιβαρή κατασκευή
• 7 endless stainless steel Dials
• Οθόνη 128 x 64 pixels, b/w, white background LED
• Πάνω από 1000 ήχοι
• 3 Oscillators per voice
• Frequency Modulation between the Oscillators
• All Q Oscillator Models
• All Microwave II/XT/XTk Wavetables
• 2 independent Multi Mode Filters per voice
• Filter FM
• 2 Drive stages per voice with selectable Drive Curves
• 3 fast LFOs per voice
• 4 fast Envelopes per voice
• Powerful Arpeggiator
• Προγραμματιζόμενο Arpeggiator Pattern με πάνω από 16 Steps σε κάθε ήχο
• 16 part multi timbralVolume Control
• Power Switch
• Stereo Output

• Headphone Output
• MIDI In
• USB Connector for MIDI In / Out
• Uses standard USB MIDI Driver provided by host computer OS
• Windows ME minimum, Windows XP or newer recommended
• Mac OS X 10.2 minimum, Mac OS X 10.3 or newer recommended
• External Power Supply
• Voice
• 3 Oscillators
• Virtual Analog Models:
• Pulse with Pulse Width Modulation and adjustable Brilliance
• Sawtooth with adjustable Brilliance
• Triangle
• Sine
• Wavetables:
• Q Alt 1 and Alt 2 Wavetable with adjustable Brilliance
• All Wavetables from Microwave II/XT/XTk Series with adjustable Brilliance
• Separate Wavetable selectable for Oscillator 1 and 2
• Frequency Modulation between the Oscillators
• Oscillator Synchronization
• Ring Modulator for Osc 1 / 2
• Noise Generator with Noise Colour
• 2 independent Multi Mode Filters
• Filter FM
• Resonance up to Self-Oscillation
• Low Pass 24 dB / 12 dB
• Band Pass 24 dB / 12 dB
• High Pass 24 dB / 12 dB
• Notch 24 dB / 12 dB
• Comb Filter with positive / negative Feedback
• PPG Low Pass Filter
• 2 Drive stages per voice with adjustable Drive Gain and selectable Curves
• Clip Hard-Medium-Soft
• Sine Shaper
• Modulation Matrix with 16 Slots, freely programmable
• Modulation Speed far into Audio Range
• Modulation Sources include all internal Modulation Sources plus various MIDI messages
• Modulation Destinations for almost all continuous sound parameters
• Various pre-routed Modulation Destinations with selectable Sources
• Pitch Modulation
• Oscillator 1 / 2 / 3 Frequency Modulation
• Oscillator 1 / 2 / 3 Pulse Width Modulation
• Filter 1 / 2 Cutoff Modulation
• Filter 1 / 2 Frequency Modulation
• Pan 1 / 2 Modulation
• Amp Modulation
• 4 Modifiers for transforming Modulation Sources with various Algorithms
• 3 fast LFOs syncable to MIDI Clock
• Note Retrigger with adjustable Start Phase
• Monophonic LFO
• Keytrack
• 4 fast Envelopes with selectable types
• Single Trigger / Retrigger per Envelope
• ADSR ADS1 DS2R (2 Decay/Sustain stages plus adjustable Attack Level)
• One Shot Loop S1S2 (Loop between Sustain 1 and 2)
• Loop All (Loop over all stages)
• Poly, Mono, Dual or Unisono Mode with selectable Voice Count
• Powerful Arpeggiator
• Hold and One Shot modes
• Syncable to MIDI Clock
• Direction Up, Down, Alternate
• Range up to 10 Octaves
• Various methods to modify Note Sort Order
• Freely programmable Arpeggiator Pattern with up to 16 Steps per Sound.
• Programmable per Step: Accent/Timing/Length
• Glide on/off
• Pause
• Chord
• Previous note
• Random not from Note List
• First and/or last note from Note List
• 1 Effect slot per part 1 Effect slot globally for all parts
• Effect types:Chorus,Flanger,Phaser,Overdrive,Triple FX (S&H, Ring Modulation, Chorus)
• Delay (only available on global Effect slot)
• Clocked Delay (only available on global Effect slot)
• Reverb (only available on global Effect slot)

- See more at: http://www.nakas.gr/ecomnakas/nakas2006/default.asp?static=421&product=133224#sthash.1jQkFepZ.dpuf

• Κατασκευαστής : Waldorf
• Supplier Code : I01WA00002
