Features:

• Compact mini size public address amplifier
• Tabletop mixer amplifier with Mp3 player, FM radio & blue tooth
• Rate power output at 60W, 120W, 240W, 350W to 500W
• Speaker output of 100V or 70V & 4 Ohm-8 Ohm-16 Ohm
• Mp3 player with USB/SD input on front panel, IR remote control for Mp3 player, FM radio and blue tooth
• LED indicators for power, clip, protect and signal
• Mic1 of balanced XLR input with dipswitch of phantom power on/off & highest VOX priority on/off
• Mic/line2-3 switchable inputs unbalanced 6.3mm jack
• Line 1-2 input of RCA input and one RCA line output
• Volume control for Mic1-3, line1-2, bass/treble and master
• Complete amplifier protection includes short-circuit, clip, overload and high temp
• AC230V power supply system

Specification:

Model

EA-60A

EA-120A

EA-240A

EA-350A

EA-500A

Description

Mixer Amplifier with USB/SD/FM/Blue Tooth

Rated Power Output

60W

120W

240W

350W

500W

Speaker Outputs

100V or 70V & 4 Ohm-8 Ohm-16 Ohm

Connector

Mic1 input by balanced XLR with phantom power & VOX highest priority

Mic/line switchable input 2-3 unbalanced 6.3mm jack

Line1-2 inputs by RCA; Line output by RCA

Input

MIC1-3: 5-8mV, 600Ω; Line, 150-470mV, 10KΩ, unbalanced RCA

Line Out

0.775(0dBV)

Frequency Response

60Hz-15kHz(±3dB)

S/N Ratio

Line ≥ 85dB, Mic≥ 72dB

THD

Less than 0.5%

Protection

Short-circuit, clip, overload and high temp protection

Power Consumption

80W

150W

310W

450W

650W

Power Supply

AC230V; 50-60Hz

Dimension

484×405×88mm

Weight

7.0kg

7.1kg

8.6kg

8.7kg

8.9kg

• Κατασκευαστής : CMX
• Supplier Code : EA-60A
