Features

• MFi microphone interface certified by Apple “Made for iPhone and iPad”
• Compatible with Mac and PC
• Direct monitor switch for real-time monitoring or for playback
• +48V Phantom Power (with 2 x AA batteries)
• Class A mic preamp with onboard gain control
• Onboard headphone output (works with the latest iPhone)
• High definition 24-bit converters with up to 96kHz sampling frequency
• Multicolor LED for easy gain settings
• Includes IK’s renowned, professional software and apps
• Ultra-light and compact
• Sleek and elegant design
• Comes with USB and Lightning cables, 2 x AA batteries and a velcro mounting strip

Specs

iRig Pre HD Specifications

Microphone Input

• Microphone Input: balanced female 3-pin, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
• Microphone Input Level: from 6 mVpp to 1.4 Vpp
• Microphone Input Impedance: 2 kOhms
• Gain Range: 40 dB
• Phantom Power: +48V ± 4V
• Frequency Response: 20 Hz - 20 kHz +/-1.5dB
• Input Noise: -97 dB RMS, -105 dB(A)

Stereo Headphone Output

• Connector: 1/8” TRS Jack. Tip: right / Ring: left / Shield: ground
• Headphone Level Control numbered thumbwheel
• Headphone Level Power 100mW into 50 Ohms

Other Input/Output

• Device Connector: micro-USB

Common

• Conversion: 24-bit A/D, 24-bit D/A
• Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz
• Power:
  • USB bus powered when used with a computer
  • Battery powered (2xAA included) needed for +48V phantom only
