- Driver Complement: super powerful 7″ (165mm) Subwoofer
- Amplifier Power: Class D, 125Wrms; 250W Max
- Frequency Response: 40Hz – 150Hz
- Fuse: 15A
- Maximum Current Draw: 14 A
- Quiescent Current Draw: <700 mA
- Input Sensitivity: 0.10 V – 5.0 V Low-Level Input; 0.5 V – 25V High-Level Input
- Crossover Frequency: 50 Hz – 150 Hz
- Crossover Slope: 12 dB/octave
- Bass Boost: 0dB to + 12dB @ 50Hz
- Dimensions (L x W x H): 10-1/4″ x 7-11/16″ x 2-5/16″ (260mm x 195mm x 58mm)
- Weight: 7.7 lbs (3.5kg)
Features
- Powerful Bass, Ultra-compact Space
- Easy Upgrade with Series Wiring Capability
- Efficient Class D amplifier
- Crossover Control
- Flexible EQ Adjustments
- ine- and High-level Inputs
- Die-Casting Aluminum Enclosure Design
- arman/Kardon’s Clean Aesthetic Desig
