SKU: 79356
Audiolab DC Block - Black 6972650929434 Audiolab DC Block - Black 6972650929434
Audiolab DC Block - Black 6972650929434
Audiolab DC Block - Black 6972650929434

Audiolab DC Block - Black 6972650929434

brand-logo

Το DC Block έχει σχεδιαστεί για να βελτιώνει την ποιότητα της ηλεκτρικής ενέργειας AC που τροφοδοτεί τα συστήματα ήχου και AV μας. Το ηλεκτρικό ρεύμα έχει θεμελιώδη επίδραση στο ηχητικό σήμα καθώς ταξιδεύει μέσω του συστήματος από την πηγή στον ενισχυτή και τα ηχεία.



Διαθέσιμο σε 10 - 30 ημέρες
€139,00 Τελική Tιμή
Προσθήκη στο καλάθι
Έχεις απορίες ή θες να κάνεις τηλεφωνική παραγγελία; Καλέστε μας στο 2109401167
Buy Now Pay Later με χρήση χρεωστικής κάρτας

Υποστηρίζουμε αγορές με δόσεις με χρήση χρεωστικής κάρτας. Για λεπτομέρειες καλέστε μας τηλέφωνο

Πληκτρολογήστε τον ταχυδρομικό κώδικα της περιοχής σας - ώστε να σας ενημερώσουμε για τους τρόπους αποστολής / παραλαβής. Δυνατότητα παραλαβής με BOX NOW
badge

Υποστήριξη μετά την πώληση

Εγγύηση προμηθευτή έωςέτη

star

Δίπλα σας από το 1976

Πάνω από 46 χρόνια εμπειρίας!

group

Γίνετε μέλος μας

Κερδίστε ειδικές προσφορές

Εναλλακτικές Προτάσεις
IFi Audio DC Blocker (5060738784196)
SKU: 49786

IFi Audio DC Blocker (5060738784196)

Άμεσα Διαθέσιμο
€149,00
€139,00
iFi Audio DC Blocker+
SKU: 86559

iFi Audio DC Blocker+

Άμεσα Διαθέσιμο
€155,00
Taga Harmony PF-1000 v.2 Silver
SKU: 46028

Taga Harmony PF-1000 v.2 Silver

Άμεσα Διαθέσιμο
€188,00
Taga Harmony PF-600 Φίλτρο ρεύματος - Silver
SKU: 69123

Taga Harmony PF-600 Φίλτρο ρεύματος - Silver

Άμεσα Διαθέσιμο
€148,00
ifi Audio GND Defender (5060738784202)
SKU: 49787

ifi Audio GND Defender (5060738784202)

Άμεσα Διαθέσιμο
€129,00
€109,00
Taga Harmony PF-1000 v.2 Black
SKU: 46029

Taga Harmony PF-1000 v.2 Black

Άμεσα Διαθέσιμο
€188,00
Taga Harmony PF-500 Φίλτρο ρεύματος – Black
SKU: 47187

Taga Harmony PF-500 Φίλτρο ρεύματος – Black

Άμεσα Διαθέσιμο
€118,00
iFi Audio AC iPurifier (5060738781812)
SKU: 0016222

iFi Audio AC iPurifier (5060738781812)

Άμεσα Διαθέσιμο
€125,00

DC mains supply

One common issue is ‘DC on the mains’ – a problem well known to affect the performance of audio equipment, especially amplifiers. In theory, the mains electricity we obtain from the sockets in our homes should be pure AC, with a perfectly symmetrical sine wave alternating between positive and negative phases. However, the presence of ‘asymmetrical loads’ – myriad household devices that use the AC energy available in the mains cycle unevenly, from dimmer switches to kitchen appliances to computer power supplies – causes the waveform to become offset, resulting in the presence of DC voltage on the AC supply.

Overview

DC Voltage

The AC transformers commonly used in home audio equipment cannot tolerate the presence of significant levels of DC voltage without being compromised. Less than 500mV of DC – typical in an average household electricity supply – can be sufficient to cause toroidal transformers of the kind often found in amplifiers to become saturated, which adversely affects sonic performance and may cause audible mechanical vibration.

By blocking, or canceling, DC voltage found within the AC mains supply, the Audiolab DC Block corrects the DC offset and rebalances the mains sine wave (see illustration above). But tackling ‘DC on the mains’ is not the only benefit delivered by this dual-action device – it also contains a high-performance audio class filtering circuit that removes RFI/EMI contaminants from the mains supply. This is effective in reducing both differential-mode noise (exacerbated by cheap switch-mode power supplies used by many home appliances) and common-mode noise (aggravated by airborne interference from phones, Wi-Fi networks, and Bluetooth).

Overview

This combination of technologies ensures that the DC Block does more than solve the problem of transformer saturation caused by DC on the mains; it also helps to unlock the sonic potential of any audio component to which it is connected. The noise floor drops and the sound gains greater focus, with reduced grain, improved clarity, better-defined bass, and ‘airier’ treble.

Power Requirement: 100-240V ~ 50-60Hz
Peak Load : 600VA
Audio Power Amplifier Compatibility <2x150W or <1x 300W
Dimensions (W x H x D): 113 x 59 x 140(mm)
Weight (net): 0.7 kg

Overview

Simple setup

Using the DC Block is simple – plug its output into the IEC power socket of an audio/AV component, then connect its input to a mains socket (both cables are provided). The device is designed for use with a single audio or AV system component – Audiolab recommends that if one DC Block is purchased, it should be used with the integrated amp or power amp component within the user’s system to obtain the greatest benefit from the DC-blocking technology. If desired, further units may be purchased to use with other electronics in the system – preamps, source components, and so on. With each additional DC Block, further incremental improvements in overall system performance can be expected.
